does anyone know, which is the chip holding the VBIOS-ROM on an AMD Pro-WX 7100?
I've two AMD Pro WX 7100 which doesn't work. One has maybe a wrong VBIOS and gets deativated in BIOS before any system boots. The other one is not recognized by the MB so I suspect this one to be defective and un-soldered two chips, which I suspect to be the VBIOS-ROM:
On earlier GPUs, the VBIOS was the chip closer to the GPU. But here, this chip has a bottom SMD contact which looks more like some power electronics...
So before I start soldering on the probably working GPU - can you tell me, which actually is the VBIOS?
Hello Fellow Tech Gurus!
I am having a huge headache after upgrading the ram memory of my m17x r3.
First let me start by saying I have been experiencing issues with my current ram setup recently, and so i decided to replace the ram inside of my computer, thinking they had gone out on me. It originally came with x4 2gb memory sticks, and as I started to experience issue, I started to removed them, and I was down to 1 2gb stick. It seems to me ram slots 1 & 2 are not working properly as when I put ram memory into them I would get BSOD in 5-10 mins of computer usage after boot. So I am thinking the slots have gone out. I also tested each slot individually and still same effect.
So I went on the try out slots 3 & 4 under the keyboard, which seems to work just fine when I use only 1 ram chip in one or the other. But the problem occurs when I try and fill both ram slots in slots 3 & 4 under the keyboard with crucial 2x 8 gb of ram sticks, which total to 16gb total ram memory.
BSOD and freezing occurs like crazy. But if I use just one of the ram sticks in either slot, no problem.
I dunno if this is hardware or software. I am think that my motherboard is on its way out the door, but any suggestions you all have would be great. I have already clean installed win 7, and is currently running bios A10 (unlocked, I believe)
I would also like to note that my motherboards internal vga is not detected, and just noticed this a few days ago upon trying to figure out the ram situation.
other issues is my laptop battery is pretty much dead, and the only for my computer to cut on is if the AC adapter is connected
I would also like to know can 1x 16gb 1600 ram stick run in my computer? or is it not supported by my motherboard?
Alienware M17xR3 (2011 3D FHD ed)
A10 (should be unlocked)
Microsoft Windows 7 Home Premium (64-bit)
Intel® Core™ i7-2960XM CPU @ 2.70GHz
Intel® 6 Series/C200 Series Chipset Family
Nvidia GTX 680m
IDT High Definition Audio CODEC
High Definition Audio Device
Networking and I/O
DW1501 Wireless-N WLAN Half-Mini Card
Atheros AR8151 PCI-E Gigabit Ethernet Controller (NDIS 6.20)
HMA TAP-Windows Adapter V9
Crucial 8 GB (x2 qty) DDR3 PC3-12800 • CL=11 • Unbuffered • NON-ECC • DDR3-1600 • 1.35V • 1024Meg x 64 •
(these only work under bay 3 or 4, but not dual 8gb at the same time, otherwise BSOD)
WDC WDBNCE5000PNC SSD (installed into bay 0)
So I just got myself a ram upgrade for the laptop which is a mech-15hs, and to my disappointment, it doesnt support XMP, but would thaiphoon burner enable that? The chips I bought are supposed to "auto-overclocked" to highest potential, but obviously it just stays stock without xmp.
These are the chips: https://www.kingston.com/dataSheets/HX426S15IB2_16.pdf
The PNP profile is 15-17-17-35-60-467 & 2666mhz and thats the same first timings as the first xmp profile at 15-17-17, so is there any point of even getting thaiphoon burner at this point? Or would using that enable xmp and auto overclock and such?
The CPU is an i7-7700hq, and I dont think anyone has gotten past 2666mhz with it anyway, so am I just beating a dead horse with TB? Or are my chips really that good out the box?
First I want to thank the community, who have inspired me to do this project.
I will give you guys the chance to follow me on this journey.
I hope you will all help me come up with ideas, techniques and parts that could become handy.
This modding may be possible to convert to allot of laptops.
Here is the measurement of the went hole.
77mm X 16mm
I have 2 ideas for what can be done.
