EwinRacing Flash Series Gaming Chairs
  • NVFlash 5.513.0 Released


    Brian

    The new leak of NVFlash version 5.513.0 with their new RTX GPU (Turing) support is now available in our download section. This includes support for NVIDIA's new RTX 2080 Ti, 2080 and 2070 desktop GPUs. As always, use caution when reading/writing vbios files as you can potentially brick your card and void your warranty.


    • Thumbs Up 1
      Report Article


    User Feedback


    Great, thanks for info!



    EDIT: ugh, just noticed it's old version

    Edited by GoMati

    Share this comment


    Link to comment
    Share on other sites

    Excellent Blog.Thank you for sharing this amazing info.If you want to download videos from YouTube then I recommend you to download tubemate 2019 app here you can easily download any videos you were like. tubemate 2020.tbe

    Share this comment


    Link to comment
    Share on other sites

    It gave me quite a scare when I did a dump of my vBios with an older version of NVFlash, because the screen goes black / flickers etc. and it takes a few seconds before it comes back again. This is normal, however I noticed when I did the same with GPU-Z it warns you this will happen and then only switches the screen once and then it's done. Maybe this new NVFlash version is better in that manner?

    Share this comment


    Link to comment
    Share on other sites


    Join the conversation

    You can post now and register later. If you have an account, sign in now to post with your account.

    Guest
    Add a comment...

    ×   Pasted as rich text.   Paste as plain text instead

      Only 75 emoji are allowed.

    ×   Your link has been automatically embedded.   Display as a link instead

    ×   Your previous content has been restored.   Clear editor

    ×   You cannot paste images directly. Upload or insert images from URL.


  • Similar Content

    • By ReverseEffect
      3dMark11 Performance Preset Benchmark: http://www.3dmark.com/3dm11/11262792

      Required items:
      1.) Lenovo u310 (I have a Core i3 - Ivy Bridge, 8GB RAM)
      2.) 65CN99WW unwhitelisted.
      3.) eGPU (I used a EVGA GTX 750 Ti from another computer I had).
      4.) EXP GDC mPCIe Edition adapter (got from eBay - banggood seller).
      5.) ATX power supply (I used a 600W PSU from another computer I had).
      6.) USB wireless.
      7.) External monitor, keyboard, and mouse.

      Steps:
      1.) Obtain and install a unwhitelisted BIOS. If you are unable to obtain a unwhitelist BIOS, I think it might be possible to bypass it with Tech Inferno Fan's Setup 1.x (may need confirmation as I haven't used it myself yet.)
      2.) Shutdown computer and remove all USB devices, ethernet cables, power cables, card reader cards.
      3.) Remove mPCIe wireless card and detach antennas.


      4.) Attach EXP GDC external mPCIe cable to the former wireless slot and screw down.


      5.) Attach HDMI end of the mPCIe cable adapter to the EXP GDC device.


      6.) Attach graphics card to the EXP GDC device (I moved my laptop off the desk and onto the side shelf to make room on the desk for the monitor/keyboard/mouse).


      7.) Using the power cable adapters that came with the EXP GDC device, I hooked in my ATX power supply's 20 pin and CPU 4 pin cables. Then hooked the other end (8 pin) into the EXP GDC device. My EVGA 750 Ti also required that I use an additional PCIe power cable (6 pin) in the top of the card.





      8.) Then I attached my misc devices (HDMI monitor, USB keyboard/mouse/wireless adapter), and hooked in my PSU and powered it on (below is image of final product, also moved HDMI cable out of the way).



      9.) Power on your computer and let it install the standard VGA drivers and then install your drivers (I didn't have to go in the BIOS for any graphics settings, which it doesn't have anyways, nor did I have to disable iGPU in Device Manager before the card was added).

      Extra Info:
      I found that most games will play on med settings with about 45 FPS with this particular card.
      BDO: Upscale on - Anti Aliasing on - SSAO off - med settings.
      Skyrim: Med-High settings.
      Fallout 4: Med settings.

      (EDIT 5/19/2016) > Images added.

    • By narbardarse
      ok, so, i have a serious problem atm.
      im trying to mod my bios so that i can go past the normal overclocking limit. however, everytime i try to do it, it always says "file size does not match existing bios size!", and it's really annoying, since i had to find everything myself, as no one else online tried this on my specific model, besides me. (which surprises me, really)
      this is the guide im following:
      So this is my detailed description how I managed to mod and overclock my GTX 960M in my Lenovo Y50-70. Please note: it is very dangerous to play with the BIOS, so you need to be very careful! I take NO RESPONSIBILITY for any damage or misuse of the information below! Use it AT YOUR OWN RISK!

      -------


      Necessary tools:
      A. Fptw64 from Intel (9.5 or above)
      http://forum.hwbot.org/showthread.php?t=75024
      B. PhoenixTool (2.50 or above)
      C. Maxwell II BIOS Tweaker (1.36)
      https://www.techpowerup.com/downloads/2562/maxwell-ii-bios-tweaker-v1-36/

      -------------------------

      How to flash Modded BIOS:
      0. Flash the latest (3.03 now) official BIOS
      1. From Windows, start 'cmd' as Administrator and read your your BIOS via Fptw64:
         Fptw64 -d BIOS.ROM -bios
      2. Reboot, enter your BIOS and check "Enable downgrading BIOS" feature (we need to downgrade first in order to flash the modded BIOS)
      3. From Windows, downgrade to 1.13 (this is necessary because the newer BIOSes have protection against mod-ding)
      4. After reboot & reflash, start Windows, then enter standby, wait a bit, then wake up the machine
      5. Create your modded BIOS, see separate list below
      6. Start 'cmd' as Administrator and write your _modded_ BIOS via Fptw64:
         Fptw64 -f BIOS_MODDED.ROM -bios

      -------------------------

      How to create modded BIOS (point 5 above):
      5.1 Start PhoenixTool.exe from Phoenix Tool 2.50 and open your previously saved original BIOS.ROM from point #1 above
       .2 The tool analyses it and shows some messages, click OK
       .3 Now you can find your vBIOS in the "DUMP" subfolder in the folder containing your BIOS.ROM, with the file name:
          BE13645B-2C2C-44D2-A64F-0EA052C34597_1796.ROM
       .4 Create your modded vBIOS, see separate list below -> let's call it 960M_OC.MOD
       .5 Click on "Structure"
       .6 Open "EFI BIOS" tag
       .7 Open second "File Volume {7A9354D9-...}" tag
       .8 DXE Core -> Compressed Section -> Raw section -> File Volume {7A9354D9-...}
       .9 In the very long list, find the following tag (usually displayed at around 80% of the list):
          Freeform {BE13645B-2C2C-44D2-A64F-0EA052C34597}
          This is the item containing the latest vBIOS
       .10 Open the tag, then "GUID defined section", then click on Raw section. "Internal number" (in the top right corner) should be 1796 for BIOS 3.03.
       .11 Click on "Replace" and select your modded vBIOS (called 960M_OC.MOD above)
       .12 Click exit "Exit" and say Yes to "Save changes?"
       .13 Close the Phoenix Tool; now you should have your BIOS.ROM updated (the original will be saved as BIOS.ROM.OLD for safety)

      -------------------------

      How to create modded vBIOS (point 5.4 above):
      Use Maxwell II BIOS Tweaker to change BE13645B-2C2C-44D2-A64F-0EA052C34597_1796.ROM;
      5.4.1 Open the ROM
         .2 Change "Boost Clock" on "Common" tab to the new boost-ed maximum value
         .3 On "Boost table" tab, use the slider in the right bottom corner to increase your max boost-ed value to the same number
         .4 On "Boost states" tab, at P00 profile, change the MAX values in the GPC, L2C and XBAR fields to the same max boost-ed value
         .5 Save your modified BIOS and rename it to 960M_OC.MOD

      (My boost-ed max value was 1359 MHz. I could then use MSI Afterburner's software tuning -> my 960M could reach 1454 MHz without voltage increase.)
      i know that it's for a different laptop, but its basically the same
      ill provide more info when im home
    • By Brentjuh2000
      Who can help me with modding and getting my 980M working?
      I replaced the M6100 that was originally in the laptop with a 980M but I can't seem to get it to work. I keep getting Code 43
      the Hardware ID : PCI\VEN_10DE&DEV_13D7&SUBSYS_15CD1028
      I heard i need to modify and INF file but i have no experience with it

      The vBIOS is from MSI


    • By Klem
      If someone wants upgrade Wi-Fi card and remove witelist, or unlock hidden additional menus and settings, or unlocked vbios for overclock NVIDIA card, then you can post your request in this thread.

      It's for Lenovo Z710, Z510 only!
    • By Andrew2009
      Please could you check if it is possible to unlock my A17 BIOS? I have Alienware 17 R5(2013). 120 Ghz 3D. gtx 980 m. I want upgrade to 1070 but I have dark picture. Turns on but does not start with 1070. 980m-All good. What could it be?
×
×
