Hi everyone,
I'm very happy with this laptop but there is an empty M.2 slot waiting to be filled. The connector seems to offer the right pins for a PCIe x4 SSD like the SM951 but someone at Notebookreview reported that this particular model dosent work. Is it possible that NVME is the problem and other PCIe SSDs should work? Could a BIOS mod help (like inserting BIOS modules)? Can I somehow determine whether the hardware supports PCIe x4 in this M.2 port?
I tried reading the PCIe configuration of the CPU with Linux, but can't interpret the result...
root@ubuntu:/home/ubuntu/Desktop# bash listpcie.sh -t
J6B2: x16 PCI Express
J6B1: x1 PCI Express
J6D1: x1 PCI Express
J7B1: x1 PCI Express
J8B4: x1 PCI Express
root@ubuntu:/home/ubuntu/Desktop# bash listpcie.sh -l
J6B2: Intel Corporation Sky Lake PCIe Controller
Flags: bus master, fast devsel, latency 0, IRQ 122
Bus: primary=00, secondary=01, subordinate=01, sec-latency=0
Capabilities: [88] Subsystem: Intel Corporation Device 2015
Capabilities: [80] Power Management version 3
Capabilities: [90] MSI: Enable+ Count=1/1 Maskable- 64bit-
Capabilities: [a0] Express Root Port (Slot+), MSI 00
Capabilities: [100] Virtual Channel
Capabilities: [140] Root Complex Link
Capabilities: [d94] #19
Kernel driver in use: pcieport
J6B1:
J6D1: Intel Corporation Sunrise Point-H PCI Express Root Port #5
Flags: bus master, fast devsel, latency 0, IRQ 16
Bus: primary=00, secondary=04, subordinate=04, sec-latency=0
I/O behind bridge: 0000d000-0000dfff
Memory behind bridge: df300000-df3fffff
Capabilities: [40] Express Root Port (Slot+), MSI 00
Capabilities: [80] MSI: Enable- Count=1/1 Maskable- 64bit-
Capabilities: [90] Subsystem: Dell Device 0706
Capabilities: [a0] Power Management version 3
Capabilities: [100] Advanced Error Reporting
Capabilities: [140] Access Control Services
Capabilities: [220] #19
Kernel driver in use: pcieport
J7B1: Intel Corporation Sunrise Point-H PCI Express Root Port #6
Flags: bus master, fast devsel, latency 0, IRQ 17
Bus: primary=00, secondary=05, subordinate=05, sec-latency=0
Memory behind bridge: df200000-df2fffff
Capabilities: [40] Express Root Port (Slot+), MSI 00
Capabilities: [80] MSI: Enable- Count=1/1 Maskable- 64bit-
Capabilities: [90] Subsystem: Dell Device 0706
Capabilities: [a0] Power Management version 3
Capabilities: [100] Advanced Error Reporting
Capabilities: [140] Access Control Services
Capabilities: [200] L1 PM Substates
Capabilities: [220] #19
Kernel driver in use: pcieport
J8B4: Intel Corporation Sunrise Point-H PCI Express Root Port #7
Flags: bus master, fast devsel, latency 0, IRQ 18
Bus: primary=00, secondary=06, subordinate=06, sec-latency=0
Memory behind bridge: df100000-df1fffff
Capabilities: [40] Express Root Port (Slot+), MSI 00
Capabilities: [80] MSI: Enable- Count=1/1 Maskable- 64bit-
Capabilities: [90] Subsystem: Dell Device 0706
Capabilities: [a0] Power Management version 3
Capabilities: [100] Advanced Error Reporting
Capabilities: [140] Access Control Services
Capabilities: [220] #19
Kernel driver in use: pcieport
Maybe someone with a little bit more experience knows what that means.
